型號 |
安裝尺寸 |
滑塊尺寸 |
|||||||||||
|
H |
E |
W2 |
W |
L |
安裝孔尺寸 |
L1 |
K |
T |
注油嘴 |
||||
|
B×J |
M×l |
安裝孔 |
T1 |
N |
|||||||||
|
SBG15SL |
28 |
2.65 |
9.5 |
34 |
58.8 |
26×26 |
M4×5 |
38.8 |
25.35 |
8 |
?3.5 |
8 |
5 |
|
SBG20SL |
30 |
3.5 |
12 |
44 |
77.2 |
32×36 |
M5×8 |
50.8 |
26.5 |
8 |
M6×0.75 |
7 |
9.8 |
|
SBG25SL |
40 |
5 |
12.5 |
48 |
86.9 |
35×35 |
M6×8 |
59.5 |
35 |
12 |
M6×0.75 |
10.5 |
9.8 |
|
SBG30SL |
45 |
6.5 |
16 |
60 |
98 |
40×40 |
M8×10 |
70.4 |
38.5 |
12 |
M6×0.75 |
11.5 |
10.7 |
|
SBG35SL |
55 |
7.5 |
18 |
70 |
109.5 |
50×50 |
M8×12 |
80.4 |
47.5 |
15 |
M6×0.75 |
16.5 |
10.7 |
|
SBG45SL |
70 |
7.3 |
20.5 |
86 |
136 |
60×60 |
M10×17 |
98 |
62.7 |
15 |
PT1/8 |
20.5 |
11 |
|
SBG55SL |
80 |
9.8 |
23.5 |
100 |
160 |
75×75 |
M12×18 |
118 |
70.2 |
18 |
PT1/8 |
22 |
11 |
|
SBG65SL |
90 |
17.5 |
31.5 |
126 |
189 |
76×70 |
M16×20 |
147 |
72.5 |
23 |
PT1/8 |
15 |
11 |
|
|
|||||||||||||
|
型號 |
導軌尺寸 |
負載能力 |
重量 |
||||||||||
|
W1 |
H1 |
F |
d×D×h |
G |
L0MAX |
動負載 |
靜負載 |
靜態扭矩(Kgf*m) |
滑塊 |
導軌 |
|||
|
C(Kgf) |
C0(Kgf) |
MR0 |
MP0 |
Mr0 |
(Kgf) |
(Kgf/m) |
|||||||
|
SBG15SL |
15 |
15 |
60 |
4.5×7.5×5.3 |
20 |
3000 |
850 |
1370 |
7 |
5 |
5 |
0.2 |
1.45 |
|
SBG20SL |
20 |
17.5 |
60 |
6×9.5×8.5 |
20 |
4000 |
1450 |
2560 |
22 |
18 |
18 |
0.33 |
2.2 |
|
SBG25SL |
23 |
21.8 |
60 |
7×11×9 |
20 |
4000 |
2140 |
4000 |
36 |
32 |
31 |
0.56 |
3.1 |
|
SBG30SL |
28 |
25 |
80 |
9×14×12 |
20 |
4000 |
2980 |
5490 |
60 |
50 |
49 |
0.98 |
4.45 |
|
SBG35SL |
34 |
29 |
80 |
9×14×12 |
20 |
4000 |
3960 |
7010 |
96 |
75 |
73 |
1.63 |
6.4 |
|
SBG45SL |
45 |
38 |
105 |
14×20×17 |
22.5 |
4000 |
6290 |
11292 |
202 |
159 |
157 |
2.96 |
11.25 |
|
SBG55SL |
53 |
45 |
120 |
16×23×20 |
30 |
4000 |
9307 |
16012 |
344 |
274 |
270 |
4.52 |
15.25 |
|
SBG65SL |
63 |
58.5 |
150 |
18×26×22 |
35 |
3000 |
15100 |
24500 |
629 |
495 |
484 |
6.55 |
23.9 |
